Ohlins DH38 - Rebuild of air spring cartridge

9
REBUILD AIR SPRING CARTRIDGE
Rebuild of air spring cartridge
Note! 1
Clean all parts using disc brake cleaner and a rag to remove dirt, old grease and
thread sealant before reassembling. Lubricate new o-rings/x-rings etc. with fresh
Assembly grease.
Note! 1
Use a vise and the appropriate shaft clamps when servicing the front fork.
1. If you used a cassette tool to undo the top cap leave the pre-
applied thread locker(reusable) and continue. If you used a 28 mm
socket clean top cap threads (male and female) using a rag covered
by degreaser or brake cleaner. Use a nylon bristled brush to remove
any remaining residue from threads.
1
Pre-applied thread locker
Continue!
