8
4
Remove the original spring support.
Install a new spring support to achieve the right
static sag.
5
Fit the spring support and the top cap. Tighten
the top cap and lock nut to a torque of 20 Nm.
CAUTION!
The piston shaft must bottom in the top cap
before the lock nut is tightened.
Original
spring
support
Adjustment
wheel
Top cap
Spring support
Refit the adjustment wheel.
Tighten the bolt in the top fork crown to 20 Nm.
NOTE!
The top nut only have to be tightened by hand
without extending tool.
New spring
support
