Ohme Cable - Product Specification; Product Description; Installation

v1.0 4
Product Specification
Voltage
220 – 250 V
Frequency
50 / 60 Hz
Power output
3-pin: 10 Amps
Commando: 32 Amps
Type 2: 32 Amps
Operating Temperature
-25⁰C to 45⁰C
Storage Temperature
-40⁰C to 85⁰C
Cable length
5 metres
Residual current function
Type A 30mA
DC 6mA
Overcurrent protection
Not fitted
Ingress protection
IP54 + partial immersion
Product Description
The Ohme Cable is an Electric Vehicle (EV) charging cable, comprising:
• Power input connector
• Charge controller, including residual current protection device
• Charging cable
• Vehicle connector
The Ohme Cable is supplied in various connection formats to make installation and use as easy as
possible.
All Ohme Cables are to be used with single phase electricity supplies (most UK houses are single
phase).
The cable is paired with the Ohme smartphone app, which allows users to control their charging to
minimise cost, minimise carbon content of their energy use and maximise battery life of their
vehicle.
The product conforms to the latest safety standards including functions to disconnect the power
supply if AC or DC current leakage occurs.
Installation
The Ohme Cable comes in three power input connector types:
