OJ Electronics OJ-DV-3030 User Manual

© 2016 OJ Electronics A/S
7
INSTRUCTIONS OJ-DV | Installation
11. Exploded and dimensioned drawings
Table 11.1
No. Description No. Description
1 Motor connection terminals 5 RJ12 Modbus connectro (2 x xslave/1 x Master)
2 Connections for future use 6 3-point stain relief for Modbus connector cable (ribbon cable)
3 Connector for optional modules 7 Power terminals (H1=L, N, PE); (H3, H4, H5=L1, L2, L3, PE)
4 Terminal strip for Modbus and A/D control signals 8 Connector for the earth (PE) protective conductor
Figure 11.1
BR1014A21b
© 2016 OJ Electronics A/S
1
3
2
4
5
7
6
8
BR1014A21b
Figure 10.4
Type:
“V”: Ventilation
“R”: Rotor
“C”: Conveyor
