39
EN
TECHNICAL DATA
GSM Standard : 900/1800 dualband
Frequency range:
E-GSM900 : 880.2 - 914.8 MHz (TX), 925.2 - 959.8
MHz (RX)
DCS1800 : 1710.2 - 1784.8 MHz (TX),
1805.2 - 1879.8 MHz (RX)
Max. radio frequency power transmitted:
GSM900 : 33 dBm ± 2 dB
GSM1800 : 30 dBm ± 2 dB
Battery (ShenZhen Utility
Power Source Co., Ltd.) BL-4C
: Lithium Ion, 3.7 V
/ 500 mAh
Max. talk time : 5 hrs.
Period of availability : 84 hrs.
USB connection : Micro USB
FM radio : 87.5 - 108 MHz
Measurements : 104.6 x 43 x 13.8 mm
MicroSD card : Support up to 32 GB
Weight : 93 g (with battery)
Plug in network supply and charger
(Shenzhen Baijunda Electronic Co., Ltd.): UT-133E-5100
Prim./sec nominal voltage Input: 100 - 240 V~, 50/60 Hz, 0.2 A
Output: 5.0 V
, 1 A
Protection class : II
IM_OMP10_180530_V04_A_HR.indb 39 30/5/18 9:07 am
