Oki Data CONFIDENTIAL
2. Operational explanation
44983601TH Rev.1
2-4 /
Note! The necessary bypass voltage in image processing is impressed on the toner feeding roller
and image developing roller as show below.
Image drum
Basic material
Toner feeding roller
While the cover is closed it will be
connected and bias will be applied
.
Image developing roller
