6. Procedures for Repairing
Oki Data CONFIDENTIAL
44983601TH Rev.1
6-3 /
Table 6-1 (2/8)
Status
level
Error
code
nnn
LCD (16 digits on the upper level
and 16 digits on the lower level)
("
" shows that nothing is
displayed on the upper level.)
LED
Contents
Ready Atten
Normal POWER OFF/ON
DATA WRITTEN OK
OFF OFF It is completed to write the NIC program data to be
updated.
It is displayed only during the special mode for the
maintenance.
Normal CHECK DATA
DATA WRITE ERROR
<%DLCODE%>
OFF ON An error occurs while the writing of the NIC
program data to be updated is processing.
It is displayed only during the special mode for the
maintenance.
%DLCODE%
acquisition error
1: Memory alloc Error
2: Download File error
3: Device free space
4: Device insufficient space error
5: File Write error
6: CU-F/W Mismatch error
Normal STATUS MODE OFF OFF It displays that the printer has started in the normal
online mode.
Normal ONLINE ON OFF ONLINE
Print data can be received.
Normal OFFLINE OFF OFF OFFLINE
To print, press the [online] switch to be online.
Normal FILE ACCESSING Not
determined
Not
determined
It is accessed to the flash memory by print job
accounting.
Since the flash memory may be damaged, the
power is not turned off during the display.
Normal DATA ARRIVE Not
determined
Not
determined
In receiving data.
Normal PROCESSING Blinking Not
determined
In receiving data.
Or Received data is being processed.
Normal DATA Not
determined
Not
determined
Received data is left.
Or the device waits for the data to be sent next.
Normal PRINTING Not
determined
Not
determined
In printing.
Normal PRINT DEMO PAGE Not
determined
Not
determined
Prints the text page.
Normal PRINT FONT Not
determined
Not
determined
Prints the font list.
Normal PRINT MENU MAP Not
determined
Not
determined
In printing the menu map.
Normal PRINT FILE LIST Not
determined
Not
determined
In printing the file list.
Normal PRINT ERROR LOG Not
determined
Not
determined
In error log printing.
Normal PRINT NETWORK CONFIG Not
determined
Not
determined
In printing the network configuration.
Normal
COPY kkk/lll
Not
determined
Not
determined
When the number of copies are two or more, the
number of copies currently printed is displayed.
Kkk shows the number of pages currently printed,
and "lll" show the total number of printed pages.
Normal CONTINUOUS PRINT Not
determined
Not
determined
In printing ROLLING ASCII.
Normal CANCELING JOB Blinking Not
determined
Received data is canceled.
Normal CANCELING JOB
(JAM)
Blinking Not
determined
Received data is canceled.
(Operation after the recovery of the paper jam)
To Next Page
