Appendix A Centronics Parallel Interface
Oki Data CONFIDENTIAL
44983601TH Rev.1
Appendix A-4 /
nStrobe
PError
H
L
H
L
H
L
nAck
T(ACK)
nStrobe
PError
H
L
H
L
H
L
nAck
T(ACK)/2 T(ACK)/2
C)DataReception(MenuSetting:Ack/BusyTiming=ArkinBusy)
d)DataReception(MenuSetting:Ack/BusyTiming=ArkinBusy)
e)I-Prime(WhenMenuSettingisnotI-PRIME=DISABLE)
Idling Idling
I/F initialization
nInit
H
L
H
L
Busy
T (INIT)
Printer
Status
Send and
Receive Buffer
Clear
Job
Cancel
MenuSetting(AckWidth) NARROW MEDIUM WIDE
T(ACK) 0.5us 1.0us 3.0us
MenuSetting(I-PRIME) 3MICRONSEC 50MICRONSEC
T(INIT) 2.0us 33.3us
MenuSetting(AckWidth) NARROW MEDIUM WIDE
T(ACK) 0.5us 1.0us 3.0us
