1.5.3 Warning / Caution display
The following warning / caution are displayed on the electrical power / sensor board.
Note!
•
There is a risk of electric shock in the middle of the heat sink and transformer. Be sure to check
before touch it.
 •
Itmayhappenthattheelectricityhasstillleftontheelectricalcircuitevenafterthefuseopened.
Warning /
Caution content record
High voltage power board
Component side Soldering side
Low voltage power board
Warning / Caution content record
Heat sink
Heat sink
Heat sink
