Oki B431L6

Oki Data CONFIDENTIAL
3. Parts replacement
44983601TH Rev.1
3-38 /
-1 Plate-Assy-Side-R
-2 Plate-Assy-Side-R
EM-30LP Class B
Apply a normal amount of MOLYKOTE
(EM-30LP) to the sliding surface with
Drum Shaft. (hatched areas)
Plate-Assy-Side-R
EM-30LP Class D
Apply MOLYKOTE (EM-30LP)
at the 3 places (120° divide)
on the hatched areas.
(Gear tooth surface)
