Oki B431L6

Oki Data CONFIDENTIAL
3. Parts replacement
44983601TH Rev.1
3-51 /
Duplex-Assy
EM-30LP Class B
Apply a normal amount of
MOLYKOTE (EM-30LP) to the
hatched areas.
(Shaft end surface side)
EM-30LP Class A
Apply a normal amount of
MOLYKOTE (EM-30LP)
to thehatched areas.
(Shaft end surface side)
Grease prohibition
EM-30LP Class B
Apply a normal amount of
MOLYKOTE (EM-30LP)
to the hatched areas.
(Shaft end surface side)
Bearing-DUP
Roller-Feed_Dup
Roller-Tensioner
Frame-Dup
Bearing-DUP
MXL87-Belt-Dup
