1.2 Printer Configuration
The printer main unit includes the following hardware parts.
• Electrophotographicprocessingpart
• Paperfeedingpart
• Controller
• Operationalpart
• Powersupplyunit
Figure1-2
B401d/B401dn/B411d/B411dn
Note!
•
Fuser-Assy has to be replaced by Assy unit.
• ItisforbiddentodisassembleFuser-AssyorreusethedisassembledFuser-Assy.
The configuration of printer main unit is shown as diagram 1-2~1-4
