BV1270SIP-OD OD Quick Start Guide Oki Electric Industry Co.,Ltd.
Page 22 of 33
STEP 2 – Part 2 Configuration File
San Jose New York
Numbering Plan
1. San Jose to New york
Using a local extension off the PBX.
Access the PBX Trunk Ports connected to the
San Jose BV1270SIP-OD unit.
Dial 11+exstension number
2. New york to San Jose
Using a local extension off the PBX.
Access the PBX Station Ports connected to the
New york BV1270SIP-OD unit.
Dial 99+exstension number
3. San Jose BV1270SIP-OD-E&M5
configuration
Office Code(Hunt Pattern:99
Trunk Group#1
Start Mode:Delay 512ms
Hunt Group Code
OKI BV1270SIP-OD
Hub/Switch
Router
Hunt Group Code
OKI BV1270SIP-OD
PSTN
Caller
Hub/Switch
Router
IP Network
OKI BV1270SIP-OD
Hunt Group Code
PSTN
New York
Daytime forwarding
number
(212) 775 8989
PBX
PBX
PBX
