Replacing consumable items> 94
5. Remove the new fuser from its packaging and remove the
transit material.
6. Holding the new fuser by its handle, make sure that it is
the correct way round. The retaining levers (2) should be
fully upright.
7. Lower the fuser into the printer.
8. Push the retaining lever (2) towards the rear of the printer
to lock the fuser in place.
Finally, close the top cover and press down firmly at both sides
so that the cover latches closed.
2
2
C
M
Y
K
