Oldham 700 TP Series User Manual

OLCT 700/710 TP
OLCT 700/710 TP Instruction Manual Rev. C.1 Page 11 of 45
3 – Arrange the braid as shown in the picture. Avoid
creating "pigtails"
4 - Insert the part back into the OLCT 710
2.7.2 Terminal Connections
CAUTION: Do not apply System power to the detector until all wiring is properly terminated and
openings are properly closed.
a) Remove the junction box cover. Identify the terminal blocks for customer wire connections (see Figure
8).
NOTE : To remove the cover, tighten the locking screw before unscrewing the cover
Locking screw
