Oldham OLCT 20 - Mechanical Installation of the Various Versions

2 – Description
6
Mechanical installation of the various versions
Please ensure you read the paragraph: Special Specifications for use in
Potentially Explosive Atmospheres in Accordance with European Directive
ATEX 2014/34/EU.
See Appendix 1 for general installation instructions.
Figure 1 : Dimensions
A
Dimensions OLC/OLCT 20
Cable length 0.2 m
