1308S20022 10-2
MODEL 1308 HEAT SEALER PARTS LISTS
ITEM NO PART DESCRIPTION PART NUMBER______QTY
001 Base 1308-0015-301 1
002 Bumper-Rubber 5902-0035 6
003 PIN-DOWEL 1/4X3/4" STST 5835-6475 2
004 Tube-Aluminum 7/8” O.D. 4639-1414-1116 1
005 Bearing-Roll End 5252-3002 2
006 Guide-Roller Film 1908-0041 2
007 O-ring 6909-3211 2
008 Rod-Film Dispensing 1308-0018 1
009 SCREW-SOCSET CUPPT 5842-6120 4
010 Tube-Film Shaft 1308-0016 1
011 WASHER-FLAT 5851-9306 2
012 Roller-Pinch 1308-0048-1 1
013 Spacer-Pinch Roller 1308-0049-1 2
014 WASHER-FLAT 1308-0050 1
015 WASHER-#10 FLAT 5851-9302 2
016 WASHER-LOCK 5851-9394 2
017 SCREW-HEX HD 10-24 5843-1231 2
101 Arm-Center 1308-0014 1
102 Shaft-Center Arm Link 1308-0001 1
103 BEARING-SINT BRZ FLNG 5254-3215 4
104 Clip-E Style (3/4” Shaft) 5840-2841 8
105 Link-Center Arm 5502-1900 2
Rev 8-15-09
To Next Page
