Page 23
46. Install second Part U - Roof Rafter using Rafter Template Spacer. Align Spacer tight against
Rafter’s 2x3 edge. Position Rafter so dado cut of Ridge Board is aligned with gap in Rafter and tight
against 2x3 edge of new Rafter. Attach as per Step 45.
47. Install Rafters as illustrated above and to the
right as per Steps 45 & 46.
48. Confirm Rafter locations using Part V (Inside Vent Framing Support) . Slide Vent
Framing Support up Rafters and adjust if necessary.
Part V - Inside Vent
Framing Support
Part V - Inside Vent
Framing Support
To Next Page
