23. Locate and open the included Heat Hinge. Follow the instructions inside the Heat Hinge Box to
fasten Hinge to the Vent Window Cleat and the Framing on the bottom of the window.
Pieces:
- 1x Heat Hinge
Hardware:
- Included in Heat Hinge Box
24. Locate Roof Short Poly. Slide Roof Short Poly up into roof section between rafters and below
Vent Window. Temporarily tack 1 - 1 1/2” Trim nail into dado in the end of the rafter to hold the poly
in place as per Step 20.
Pieces:
- 1x Roof Short Poly
(1/4” x 20” x 26 3/4”)
Hardware:
- 1x 1 1/2” Trim Nails
Below Vent Window
