Olympia NC 620 - Self-Diagnosis; Error Table; Maintenance

17
Giu
Self-diagnosis
Display Cause Solution
Left counting
sensor
The left-hand counting sensor is soiled
or damaged.
Clean or change the sensor.
Right count
ing sensor
The right-hand counting sensor is soiled
or damaged.
Clean or change the sensor.
Middle Mag
netic sensor
The magnetic head is defective. Change the magnetic head.
UV Sensor The UV lamp tube is defective or the
UV sensor is damaged.
Change the UV lamp tube or UV sensor.
Hopper
Sensor
The sensor in the infeed tray is soiled
or damaged.
Clean or change the sensor.
Stacker
Sensor
The sensor in the output tray is soiled
or damaged.
Clean or change the sensor.
Error table
Display Test Function Sensor Indication
EC Stuck together (Always active)
EH Half bank notes (Always active)
JAM Jammed bank notes -
Ed Double bank notes / Density DEN
dd Width of bank note DD
CF-1 Ultraviolet test UV
CF-2 Magnetic ink test MG
CF-3 Incorrect bank note when sorting -
CF-4 Infrared test IR
CF-5 Length of bank note 3D
CF-6 Imprint on bank note CIS
Maintenance
 Switch the machine off prior to cleaning.
 Clean off dust with a soft, clean brush or a soft, lint-free
cloth.
 Clean the sensors after each use.
 Clean the magnetic head, UV lamp tube and UV
sensor using a soft cloth moistened with isopropyl alcohol.
 Do not use any cleaning agents or solvents.
Disposal
The adjacent symbol indicates that old electric
al and electronic apparatus and batteries
must be disposed of separate from normal
household waste, in compliance with legal require
ments.
Packaging materials must be disposed of according to
local regulations.
Guarantee
Dear Customers,
we are very pleased that you have decided to buy this
product.
In the case of a defect, please return the device togeth
er with the receipt and original packing material to the
point-of-sale.
