Specifications
Type: TTL auto-exposure 35mm SLR camera
Film Format: 24mm × 36mm
Lens Mount: Olympus OM mount
Shutter: Electronically controlled cloth focal plane shutter; 1/1000 sec. max.
shutter speed; 1/60 sec. mechanical shutter speed
Synchronization: X contact (synchronization at speeds of 1/60 sec. or slower;
hot
shoe
with
contact
for
T-series
flash;
5-pin
connector
for
T-series
flash;
PC synchro socket
Metering system: Olympus direct metering in body; viewfinder display for
center-weighted averaged metering and spot metering; TTL direct (off-
the-film) light metering for automatic exposure control; SBC photocell
Programmed Automatic Exposure: Type: Programmed exposure control on
TTL
direct
"off-the-film"
light
measuring (center-weighted
average
light
measurement); exposure control range: about 1 min. ~ 1/1000 sec.; light
measuring range: approx. -5EV ~ 18EV (ISO/ASA 100, 50mm F1.4,
normal temperature and humidity); Flash control: Automatic flash ex-
posure at 1/60 sec. or slower speeds with T-series flash; programed auto-
matic aperture control
Aperture-preferred Automatic Exposure: Type: Automatic exposure control
by TTL
direct
"off-the-film"
light
measuring
with
aperture-preferred
elec-
tronic shutter (center-weighted average light measurement); exposure con-
trol range: about 1 min. ~ 1/1000 sec.; light measuring range: approx.
-5EV~ 18EV
(ISO/ASA
100,
50mm
F1.4,
normal
temperature
and
humidity);
Flash
control:
Automatic
flash
exposure
at
1/60
sec.
or
slower
speeds with T-series flash
Manual Exposure: Mechanical shutter for B and 1/60 sec., electronic shutter
for 1 ~ 1/1000 sec,; fixed point exposure setting; spot metering on micro-
prism of focusing screen 1-13; flash synchronization at 1/60 sec. or
slower
Exposure Compensation: 2 steps and 1/3 step
Film Speed: I SO/ASA 12 ~ 3200
Film
Advance:
Film
advance
lever
with
130°
angle
for one
long
or
several
short strokes and pre-advance angle 30 ; motor drive and winder usable
Film Rewind: Rewind crank
Self-timer: 12 sec. delay electronic self-timer
Power Source: Tow 1.5V silver-oxide batteries SR44 (Eveready EPX-76) or
alkaline manganese batteries LR44
Battery Check: 3-level display with LED and alarm sound; automatic lock
with batteries exhausted
Viewfinder: Pentaprisrn type wide-vision finder; interchangeable focusing
screens; microprisrn/split image-matte type screen standardized; finder
view field: 97% of actual picture field; magnification: 0.86x at infinity with
50mm lens
Viewfinder Information: 1) Shutter speeds; 1/3 EV-step bar display of
1 ~ 1/1000 sec. 2) Display in programmed mode: PRGM signal and
blinking of OVER to indicate that the aperture has to be stopped
down. 3} Fixed point display in manual mode 4) Blinking of OVER for
overexposure 5) Blinking of + - for exposure compensation 6) dis-
play
at
"60"
with
flash installed
7)
Green
LED
lights
with
flash
fully
charged 8) On firing flash, green LED blinks to indicate correct exposure;
OVER blinks for overexposure, and UNDER for underexposure
Camera Back: Removable hinge type, with memo holder; interchangeable
with Recordata Backs and 250 Film Back
Dimensions: 136 × 84 × 50mm (5.35" × 3.30" × 1.97") (body alone)
Weight: 540g. (19 oz.) (body alone)
