Standard program diagram
The OM-88 permits programmed exposure
only when an Olympus AF or PF Lens is
mounted on it. The standard program
diagram shows that while the aperture is
fixed at the maximum aperture (1.8) with
shutter of 1/60 sec. or slower, the aperture
and shutter speed vary at a 45 slope with
shutter speeds faster than 1/60 sec.
[E] Shutter speed
[E] Aperture
35
