9
BX3M-PSLED
3 Specifications
Item Specification
Rating
Main unit: input: 5 V / 2.5 A
AC adapter: input: 100-240 V 50-60 Hz 0.4 A output: 5 V 2.5 A
Power consumption 5.3 W, 17.2 VA
Cooling system Natural circulation air cooling
The number of controllable
LED system
1 system
Brightness adjustment
Adjustment by the knob
Current value of maximum brightness: 700 mA
Dimensions and weight 43(W) x 111(D) x 85(H) mm 360g
Operating environment
· Indoor use
· Altitude: Max. 2,000 meters
· Ambient temperature: 5 to 40 °C (41 to 104 °F)
· Maximum relative humidity: 80% for temperatures up to 31 °C (88 °F) (without condensation)
In case of over 31 °C (88 °F), the relative humidity is decreased linearly through 70% at 34 °C (93 °F),
60% at 37 °C (99 °F), and to 50% at 40 °C (104 °F).
· Supply voltage fluctuations: Not to exceed ±10% of the normal voltage.
· Pollution degree 2 (in accordance with IEC60664-1)
· Installation/Overvoltage category :
(in accordance with IEC60664-1)
