4
EN
Quick Start Guide
Prepare the camera
a. Charge the battery.
( Battery comes partially charged.
b. Insert the battery and an xD-Picture Card (optional).
1
Red light on: Charging
Light off: Charging complete
(Charging time: Approx. 5 hours)
AC Wall
Outlet
Power Cable
Battery
Charger
Lithium Ion Battery
3
W
2
Charging Indicator
3
( To remove the battery, press the battery
lock knob in the direction of the arrow.
1
2
( Insert the battery by
putting in the marked
side first, with the
marks toward the battery
lock knob.
If you insert the battery
incorrectly, you will not be able to
remove it. Do not use force.
Contact authorized distributors/
service centers.
Damage to the battery exterior
(scratches, etc.) may produce
heat or an explosion.
Battery lock knob
To Next Page
