34
Chapter 2 Instrument Nomenclature and Specifications
EVIS EXERA II GIF/CF/PCF TYPE 180 Series OPERATION MANUAL
6. Confirm that the fitting is securely attached to the foot of the S-cord
connector mount or the chain connector of the GIF-N180 and can be
smoothly rotated.
Figure 2.2
Figure 2.3
The instructions on the remaining pages of this manual are
given under the assumption that the chain for the
water-resistant cap is detached from the endoscope.
Connecting plate
Notch
Pin
Venting connector
Water-resistant cap
Fitting part
Hole
S-cord connector
mount or chain
connector
To Next Page
