44
Chapter 3 Cleaning, Disinfection and Sterilization Procedures
EVIS EXERA GIF/CF/PCF TYPE 160 Series REPROCESSING MANUAL
Flushing detergent solution into the air/water channels
1.
Attach the channel plug’s biopsy valve cap to the instrument channel port
(see Figure 3.25).
2. Lower the channel plug’s cylinder plug onto the air/water and suction
cylinders and slide the plug until it stops (see Figure 3.25).
Figure 3.25
3. Attach the injection tube’s connector plug to the air and water supply
connectors on the endoscope connector (see Figure 3.26).
4. Attach the injection tube’s air pipe port to the air pipe on the endoscope
connector (see Figure 3.26).
5. Attach the injection tube’s suction channel tube to the suction connector on
the endoscope connector (see Figure 3.26).
6. Immerse the suction port of the injection tube in the detergent solution.
Figure 3.26
