14
28LBA15 (LBA filter) [Optional]
Item Specifications
Filter type Color temperature conversion filter
Color temperature conversion
capability
15 decamired
Dimension Ø28 mm / Thickness: 2 mm
Weight Approx. 4 g
LG-KLADP (Socket for KL light guide) [Optional]
Item Specifications
Attachable light guide SCHOTT light guide for KL1600LED
Dimension Ø23 mm / Length: 39.3 mm
Weight Approx. 15 g
Other light guides
Item Specifications
Product name LG-R66 LG-DI LG-DFI LG-DF LG-SF
Corrugated
tube
Type
Flexible tube Interlock tube Flexible tube Interlock tube Flexible tube Flexible tube
Length 1000 mm 500 mm 1000 mm 500 mm 1000 mm 1000 mm
Fiber Type
Multicomponent glass: Ø50 μm
Bundle
diameter
Light-incident
side
Ø8 mm Ø8 mm Ø8 mm Ø6 mm Ø6 mm
Light-emitting
side
Ø70 x 0.22 mm Ø5.66 mm Ø5.66 mm Ø4.24 mm Ø6 mm
Minimum bending radius 33 mm 60 mm 33 mm 60 mm 33 mm 33 mm
Light intensity balance
between two light guides
of dual light guide
– 90% or more 90% or more 90% or more –
