Olympus LG-LSLED - Attaching LG-R66 (Ring Light Guide)

16
SZX10, SZX7
Loosen the clamping knob
B
of LG-R66 (Ring light guide)
A
.
Insert SZX-LGR66 (Ring light guide adapter for SZX)
C
into
LG-R66
A
completely to the end and tighten the clamping knob
B
.
Loosen the clamping screw
D
of SZX-LGR66
C
sufficiently using
the Allen screwdriver provided with the microscope frame.
Insert SZX-LGR66
C
into the objective of SZX, align the surface of
objective with the bottom surface of LG-R66, and tighten the clamping
screw
D
using the Allen screwdriver.
1
2
3
4
3
Attaching LG-R66 (Ring light guide)
1
3
B
A
C
SZ61, SZ51
Screw in SZ-LGR66 (Ring light guide adapter for SZ)
A
completely to
the thread of the auxiliary objective of the SZ2 microscope.
Loosen the clamping knob
C
of LG-R66 (Ring light guide)
B
.
Insert LG-R66
B
into SZ-LGR66
A
completely to the end and tighten
the clamping screw
C
.
1
2
3
SZX16
Loosen the clamping knob
B
of LG-R66 (Ring light guide)
A
.
Insert LG-R66
A
upward until it contacts the objective bottom surface
C
, and tighten the clamping knob
B
.
1
2
A
A
B
B
C
C
D
2
2
4
