Names of parts
12 EN
Names of parts
j
ghi
d
e
f
1
2
3
5
4
6
7
8
0
9
a
5
b
c
1 Mode dial ........................................P. 27
2 Shutter button .................................P. 28
3 ON/OFF button ..............................P. 20
4 Control dial (P)
.............................P. 50 – 53, 68, 71, 100
5 Strap eyelet.....................................P. 14
6 Self-timer lamp/AF illuminator
............................................. P. 73/P. 111
7 Lens attachment mark ....................P. 18
8 Mount (Remove the body cap before
attaching the lens.)
9 Hot shoe cover
0 Internal fl ash ...................................P. 71
a Stereo microphone ....... P. 105, 114, 116
b Lens release button ........................P. 19
c Lens lock pin
d Tripod socket
e Battery/card compartment lock
..................................................P. 15, 17
f Battery/card compartment cover
..................................................P. 15, 17
g Connector cover
h HDMI micro connector ..................P. 130
i Micro-USB connector............P. 140, 142
j Card slot .........................................P. 17
