Olympus Pen E-PL9 - Attaching a lens to the camera

Preparation
1
18 EN
Attaching a lens to the camera
1
Remove the rear cap of the lens
and the body cap of the camera.
1
2
1
2
Rear cap
2
Align the lens attachment mark (red) on
the camera with the alignment mark (red)
on the lens, then insert the lens into the
camera’s body.
Lens attachment mark
3
Rotate the lens clockwise until you hear it
click (direction indicated by arrow 3).
3
• Make sure the camera is turned off when attaching or removing the lens.
• Do not press the lens release button.
• Do not touch internal portions of the camera.
 Removing the lens cap
1
1
2
1
1
2
