4
Item Specification
Illuminator
control
LED type Reflected light illuminator: MM6-ILW
Transmitted light illumination:
M
M6-ILG
Illuminator for focus navigator unit
: MM6-ILG
Driving current
330 mA ±20 mA(max)
Power consumption
Approx. 2 W per illumination
Average life Approx. 30000 hours (Ambient temperature 20 °C, light intensity level 50%)
Pilot lamp ON:
The main s
witch of the control box is turned ON.
OFF: The main switch of the control box is turned OFF.
Indicator REMOTE ON:
The measuring micr
oscope can be controlled by the basic software STM7-BSW.
OFF:
The measuring micr
oscope cannot be controlled by the basic software STM7-BSW.
ERROR ON (Blink):
The err
or is found.
OFF: The error is not found.
HS (manual frame
only)
ON: The control box is connected to the hand switch STM7-HS.
OFF:
The contr
ol box is not connected to the hand switch STM7-HS.
MCZ (motorized
frame only)
ON:
The contr
ol box is connected to the focus controller STM7-MCZ.
OFF: The control box is not connected to the focus controller STM7-MCZ.
Z SCALE (motorized
frame only)
ON:
The Z axis scale is connected pr
operly.
OFF:
The Z axis scale is not connected pr
operly.
AF (motorized frame
only)
ON:
ON: The contr
ol box is connected to the autofocus unit STM7-AF.
OFF:
The control box is not connected to the autofocus unit STM7-AF.
HALF ON:
The counter data of X
-, Y- and Z-axis is displayed in 1/2 value of the actual movement
distance.
OFF: The counter data of X, Y and Z axes is displayed normally.
EPI SEL ON: The reflected light illumination can be controlled.
OFF:
The r
eflected light illuminator cannot be controlled.
DIA SEL ON:
The tr
ansmitted light illumination can be controlled.
OFF:
The tr
ansmitted light illumination cannot be controlled.
FN SEL ON: The illumination for focus navigator unit can be controlled.
OFF: The illumination for focus navigator unit cannot be controlled.
F FINE (motorized
frame only)
F FINE ON:
The mo
vement distance of the fine/coarse focusing knob of the focus
controller STM7-MCZ is small.
F COARSE ON:
The movement distance of the fine/coarse focusing knob of the focus
controller STM7-MCZ is large.
F COARSE
(motorized frame
only)
AF TRACK
(motorized frame
only)
ON:
The autofocusing is in T
rack mode.
OFF:
The autofocusing is in One-Shot mode.
Z LIMIT (motorized
fr
ame only)
ON:
The lo
wer software limit of the focus area is set.
OFF:
The lo
wer software limit of the focus area is not set.
DIP switch/ Rotary switch For settings of DIP switch (SW1), DIP switch (SW2) and Rotary switch (SW3), refer to
“Instruction manual of Measuring Microscope STM7”.
1 Specifications
