7. APPENDIX ………………………………………………………. 32
7.1. Primary AC selection ……………………………………………. 32
7.2. Controlling OM4001A with FLEX Radio Series 6xxx ……………. 34
7.3. OM4001A Remote Control ………………………………..………. 36
7.4. Remote Control using own public IP Address ............................. 40
7.4.1. Changing OM4001A+ connection settings ................................. 40
7.4.2. Setting up in the Remote software ............................................... 41
7.4.3. Remote Control without own IP Address, behind a router .......... 42
7.5. OM4001A firmware upgrade …………………………..………… 43
7.6. Icom connection with OM4001A ……………………………….… 47
7.7. Yaesu plus BPF plus ANT Switch connection with OM4001A … 48
7.8. Control panel connectors pin-out …………………………….…… 49
7.9. Block Diagram of the OM4001A Power Amplifier …………..… 53
7.10. Troubleshooting ………………………………………………………. 54
