Pin 9 - BAND data A - output BCD Yaesu BAND data compatibile code.Use for automatic bandpass filter
OM6BPF
Pin 10 - BAND data B - output BCD Yaesu BAND data compatibile code.Use for automatic bandpass filter
OM6BPF
Pin 11 - BAND data C - output BCD Yaesu BAND data compatibile code.Use for automatic bandpass filter
OM6BP
Pin 12 - BAND data D - output BCD Yaesu BAND data compatibile code.Use for automatic bandpass filter
OM6BPF
Pin 13 - Not connected
Pin 14 - GND
Pin 15 - 12V /100mA – the same as pin 8
OM2000A+ can address up to 10 antenna port, see antenna BCD code table below
D
C
B
A
Logic value
Antenna port
0
0
0
0
0
UNDEFINED
0
0
0
1
1
ANT 1
0
0
1
0
2
ANT 2
0
0
1
1
3
ANT 3
0
1
0
0
4
ANT 4
0
1
0
1
5
ANT 5
0
1
1
0
6
ANT 6
0
1
1
1
7
ANT 7
1
0
0
0
8
ANT 8
1
0
0
1
9
ANT 9
1
0
1
0
A
ANT 10
1
0
1
1
B
UNDEFINED
1
1
0
0
C
UNDEFINED
1
1
0
1
D
UNDEFINED
1
1
1
0
E
UNDEFINED
1
1
1
1
F
UNDEFINED
