Parts Breakdown
Model VR08 41215 General Assembly
Evaporator Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
66438
Controller, ELE BEV 115V N/SEN for
41215
1 66440 Grill, Wire Rear VL08 for 41215 3 66442 Front Grill, THER BK for 41215 5
66439 Pilaster, 1046 7B Diam 6.7 for 41215 2 66441 Shelf for 41215 4 66443 Leveling Screw, 1/2”-13x1 1/2” for 41215 6
Item No. Description Position Item No. Description Position Item No. Description Position
66444
Evaporator 14T 5/16 CU 6FPI FIL299
for 41215
1 66446 ABS Motor Evaporator Support for 41215 4 66438
Controller, ELE BEV 115V N/SEN for
41215
7
66405 Cap Tube 0.036x96” for 41215 2 66447
Motor E WEL 1/70HP 115V 50/60HZ
1800RPM for 41215
5
66445
Evaporator Housing ABS N/Slot for
41215
3 66448
Fan Blade, WEL PLA 8” Diam. 28 Deg.
for 41215
6
Item No. Description Position Item No. Description Position Item No. Description Position
66449
LED Driver, VB-12030D018 30W 115V
50/60Hz for 41215
1 66451
Condenser, HEL 13S 5/16 CU SQU for
41215
4 66453 Nylon T Motor BOT Support for 41215 7
66402 Rocker Switch, BK for 41215 2 66452 ABS Condenser Pan for 41215 5 66454
Fan Blade, WEL PLA 8 3/4 Diam. 25
Deg. for 41215
8
66450
Compressor SEC TTE4.6FK 115V 60Hz
for 41215
3 66447
Motor E WEL 1/70HP 115V 50/60Hz
1800RPM for 41215
6 66425 Power Cord 115V 15A 14AWG for 41215 9
Item No. Description Position Item No. Description Position Item No. Description Position
66455 Module, 6 LEDS 1.2W 12V for 41215 1 66434 MET Top Hinge UNI Slope OPT for 41215 3 66458
Universal Door Gasket 478x1413mm
for 41215
5
66456
MET Bottom Hinge RIG SCC TR34.5
for 41215
2 66457
Door G J Rig LED Standard V10 SCC
BDH for 41215
4 66459
Door Handle, PLA Standard V7.2 for
41215
6
