Parts Breakdown
Model VR06 41214 General Assembly
Evaporator Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
66393
Leveling Screw, 1/2”-13x2” W/PLA UL
for 41214
1 66397 Grill, MET Containment R2 for 41214 5 66399 Clip, F/Pilaster 16G Polished for 41214 9
66394 Pilaster, 428 4B Diam 6.7 for 41214 2 66398 Grill, MET Containment C02 for 41214 6 66400 Thermometer, Wall MTG for 41214 10
66395
Controller, ELE BEV 115V N/SEN 6T
for 41214
3 72281 Top Shelf for 41214 7
66396 Knob, ABS Control for 41214 4 72284 Bottom Shelf for 41214 8
Item No. Description Position Item No. Description Position Item No. Description Position
66401 Temp Sensor, ETC1H 2.0M for 41214 1 66404
Return Pipe, 1/4” 0.300M R6 UL for
41214
4 66407
Motor, E WEL 13W 100/240V 50/60HZ
1400RPM for 41214
7
66402 Rocker Switch, BK for 41214 2 66405 Cap Tube 0.036x96” for 41214 5 66408
Fan Blade MYF PLA 6” Dia. 31 Deg.
for 41214
8
66403
Evaporator 156 14T 1/4 AL 6FPI FIL341
PAI for 41214
3 66406
Grill, Wire Fan Blade 200mm 12R WT
High for 41214
6 66409 Nylon Motor Ring for 41214 9
Item No. Description Position Item No. Description Position Item No. Description Position
66410 Main Harness for 41214 1 66416 ABS Condenser Pan for 41214 7 66422 Suction Pipe 1/4” 0.980M for 41214 13
66411 LED Harness for 41214 2 66417 Filter Dryer 0.9 HP DCL for 41214 8 66423
Motor, E WEL 13W 100/240V 50/60HZ
1400RPM for 41214
14
66412 Compressor Harness for 41214 3 66418 Cond-Filt Pipe 3/16” 0.180M for 41214 9 66424
Fan Blade, WEL PLA 8” Diam. 28 Deg.
for 41214
15
66413
LED Current, Driver 24W R2 S300 W/
CON for 41214
4 66419 Charge Pipe 1/4” 0.180M for 41214 10 66425 Power Cord 115V 15A 14AWG for 41214 16
66414
Compressor EMB EMU40CLP 115V
60HZ R6 for 41214
5 66420 Discharge Pipe 3/16” 1.010M for 41214 11
66415
Condenser 206 NFI 36T 3/16 FE PAI HM
for 41214
6 66421 Vacuum Pipe 1/4” 0.300M for 41214 12
Item No. Description Position Item No. Description Position Item No. Description Position
66426
Module, 8 LEDS 1.2W 54MA NGD for
41214
1 66430 PE BLA NGD Couple for 41214 5 66434
MET Top Hinge UNI Slope OPT for
41214
9
66427 F-M Moduled Harness NGD for 41214 2 66431
Door G J RHG LED SCTB NGD for
41214
6 66435 Hinge Top Cover for 41214 10
66428
F-Driver Moduled Harness NGD for
41214
3 66432
Universal Door Gasket 516x866mm for
41214
7 66436 Hinge Position Top Cover for 41214 11
66429
Reversible Door Stopper ED 3/4” BK
for 41214
4 66433 Door Handle for 41214 8 66437
MET Top Hinge UNI Slope SCTB for
41214
12
To Next Page
