Omcan Imbera VFS24 User Manual

40
Parts Breakdown
Model VR12 41217 General Assembly
Evaporator Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
AD562 Pilaster for 41217 1 AD571 Driver 24W for 41217 10 AD578 Magnetic Support Switch for 41217 19
AD563 Anti-Vacuum Moulding for 41217 2 AD572 Power Cord for 41217 11 AD579 Control Knob for 41217 20
AD564 Tube Cover for 41217 3 AD573 Back Grill for 41217 12 AD580 Main Harness for 41217 21
AD565 Mold Deector Support for 41217 4 AD574 Shelf for 41217 13 AD581 Harness Motor for 41217
AD566 Deector Molding for 41217 5 66645 Clip F/Pilaster for 41217 14 AD582 LED Harness for 41217
AD567 Wire Cover for 41217 6 66507
Thermometer, Wall MTG, 3017492 for
41217
15 AD583 Motor Ground Harness for 41217
AD568 Switch for 41217 7 AD575 Leveling Leg for 41217 16 AD584 Compressor Harness for 41217
AD569 Temperature Control for 41217 8 AD576 Wall Spacer for 41217 17
AD570 Control Support for 41217 9 AD577 Front Grill for 41217 18
Item No. Description Position Item No. Description Position Item No. Description Position
AD585 Stopper for 41217 1 AD587 Hose for 41217 5 AD591 Capillary Tube 0.036”x150” for 41217 9
AD586 Evaporator Fan Motor for 41217 2 AD588 Temperature Sensor for 41217 6 AD592 Evaporator Housing for 41217 10
66477
Fan Blade Elc Pla 8” Diam. 28 Deg.
for 41217
3 AD589 Evaporator for 41217 7 AD593 Evaporator Housing Grill for 41217 11
66493
ABS O Motor Evaporator Support for
41217
4 AD590 Heat Exchanger for 41217 8
Item No. Description Position Item No. Description Position Item No. Description Position
AD608 LED Module for 41217 1 AD614 Glass Door for 41217 7 AD619 Bottom Hinge for 41217 13
AD609 F-M Module Harness for 41217 2 AD615 Gasket for 41217 8 AD620 Hinge Cover Position for 41217 14
AD610 F-M Module Harness for 41217 3 AD616 Plastic Door Handle for 41217 9 AD621 Top Hinge for 41217 15
AD611 Moulding Glass Fixer Cover for 41217 4 AD617 Removable Rivet for 41217 10 AD622 Moulding Glass Fixer Cover for 41217 16
AD612 Moulding Glass Fixer Cover for 41217 5 66559 Self Closing G319 UL V10 for 41217 11
AD613 Stopper for 41217 6 AD618 Bottom Hinge for 41217 12
Item No. Description Position Item No. Description Position Item No. Description Position
AD594 Compressor Base for 41217 1 AD599 Pipe Support for 41217 7 AD603 Condensate Pan for 41217 13
AD595 Condenser for 41217 2 66477
Fan Blade Elc Pla 8” Diam. 28 Deg. for
41217
8 AD604 Discharge Pipe for 41217 14
AD596 Condenser Pan Support for 41217 3 66476 Nylon T Motor Injected Support for 41217 9 AD605 Suction Line for 41217 15
AD597 Filter Drier for 41217 4 AD600 Motor Stand for 41217 10 66668
Condenser Fan Motor, 16W 1850RPM
for 41217
16
66419 Charge Pipe 1/4” 0.180M for 41217 5 AD601 Hose for 41217 11 AD606 Acc Compressor Kit for 41217 17
AD598 Vacuum Pipe for 41217 6 AD602 Compressor for 41217 12 AD607 Pipe Insulation for 41217 18
