Parts Breakdown
Model VR10 41216 General Assembly
Evaporator Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
66460 Grill, Wire Rear VR10x12 UL for 41216 1 66443 Leveling Screw, 1/2”-13x1 1/2” for 41216 5 66400 Thermometer, Wall MTG for 41216 9
66461 Shelf for 41216 2 66463
Kit Visislide Low 6 FTES CCE V12 for
41216
6 66438
Controller, ELE BEV 115V N/SEN for
41216
10
66399 Clip, F/Pilaster 16G Polished for 41216 3 66464
Front Grill, THER BK V14 L/RHinge PL
for 41216
7
66462 Pilaster 212 3B Diam 6.7 for 41216 4 66396 Knob, ABS Control for 41216 8
Item No. Description Position Item No. Description Position Item No. Description Position
66470 Main Harness ETC1H BL for 41216 1 66417 Filter Dryer 0.9 HP DCL for 41216 7 66477
Fan Blade ELC PLA 8” Diam. 28 Deg.
for 41216
13
66471
Accumulator CU 1 3/8” Diam.x4” for
41216
2 66473 Discharge Pipe 1/4” 1.000M for 41216 8 66478 Arnes Unidas ETC1H UL for 41216 14
66449
LED Driver, VB-12030D018 30W 115V
50/60HZ for 41216
3 66419 Charge Pipe 1/4” 0.180M for 41216 9 66425 Power Cord 115V 15A 14AWG for 41216 15
66472
Compressor EMB EMI55HER 115V 60HZ
for 41216
4 66474 Vacuum Pipe 1/4” 0.450M for 41216 10 66402 Rocker Switch, BK for 41216 16
66451
Condenser, HEL 13S 5/16 CU SQU
for 41216
5 66475
Motor, E ELC 16W 115V 50/60HZ
1850RPM for 41216
11
66452 ABS Condenser Pan for 41216 6 66476 Nylon T Motor Injected Support for 41216 12
Item No. Description Position Item No. Description Position Item No. Description Position
66479 PVC Drain Curved Coupler for 41216 1 66482
Met Bottom Hinge LEF SCC TR34.5
for 41216
5 66486
Universal Door Gasket 628x1098mm
for 41216
9
66434 Met Top Hinge UNI Slope OPT for 41216 2 66483 F-M Moduled Harness for 41216 6 66455 Module, 6 LEDS 1.2W 12V for 41216 10
66480 Hinge Top OPT BL Cover for 41216 3 66484 F-Driver Moduled Harness for 41216 7
66481
MET Bottom Hinge RIG SCC TR34.5
for 41216
4 66485 Door G J RHG LED SCC BDH for 41216 8
Item No. Description Position Item No. Description Position Item No. Description Position
66465
Evaporator 150 14T 5/16 CU 6FPI FL400
for 41216
1 66466 Evaporator Housing MET 4N for 41216 3 66468 Rocker Switch, BK for 41216 5
66405 Cap Tube 0.036x96” for 41216 2 66467
Motor E WEL 1/70HP 115V 50/60HZ
1800RPM for 41216
4 66469 Temp Sensor, ETC1H 1.0M for 41216 6
