Parts Breakdown
Model G319 HC 45445 General Assembly
Evaporator Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
62480 Back Grill for 45445 1 66443 Leveling Screw, 1/2”-13x1 1/2” for 45445 4 66506
Controller ELE BEV 115V N/SEN 6T
for 45445
7
AD560 Shelf G313x16x19 UL Black for 45445 2 66504 Front Grill, Ther BK Hole for 45445 5 66396 Knob, ABS Control for 45445 8
66399 Clip, F/Pilaster 16G Polished for 45445 3 AD561
Kit Visislide Low 8 FTES CCE V12 Black
for 45445
6 66507
Thermometer, Wall MTG, 3017492 for
45445
9
Item No. Description Position Item No. Description Position Item No. Description Position
66508
Evaporator 332 20T 1/4 AL 6FPI FIL490
PAI for 45445
1 66511 Cover, PLA CTRL WT G3 for 45445 4 66402 Rocker Switch, BK for 45445 7
66509 Cap Pipe, 0.049x120” for 45445 2 66512
Motor E WEL 1/70HP 115V 50/60HZ
1800RPM for 45445
5 66514
Temperature Sensor 3M ETC1H for
45445
8
66510 Evaporator Housing ABS for 45445 3 66513
Fan Blade, WEL PLA 8” Diam 28 Deg.
for 45445
6
Item No. Description Position Item No. Description Position Item No. Description Position
66515
LED Current, Driver 24W R2 S450 W/
CON for 45445
1 66518 ABS Condenser Pan EV46x72 for 45445 5 66519
Suction Pipe 5/16” 1.400M CCV144 R2
for 45445
9
66425 Power Cord 115V 15A 14AWG for 45445 2 66417 Filter Dryer 0.9 HP DCL for 45445 6 66520
Motor E WEL 1/70HP 115V 50/60HZ
1800RPM for 45445
10
66516
Compressor SEC DEL-6.5CN 115V 60HZ
R2 for 45445
3 66419 Charge Pipe 1/4” 0.180M for 45445 7 66512
Motor E WEL 1/70HP 115V 50/60HZ
1800RPM for 45445
11
66517
Condenser 388 NFI 72T 3/16 FE PAI UL
HM for 45445
4 66474 Vacuum Pipe 1/4” 0.450M for 45445 8 66454
Fan Blade, WEL PLA 8 3/4 Diam. 25
Deg. for 45445
12
Item No. Description Position Item No. Description Position Item No. Description Position
66521
Harness, Door HG NGD UL 1DRV for
45445
1 66524
Door G J RHG LED SCC W/Wire BDH
for 45445
4 69050 Hinge - Met Bot LEF SCC G00 for 45445 7, 8
66522
Module, 8 LEDS 1.2W 54MA V7 Serie
for 45445
2 66525
Door Gasket Universal 748x1627mm
for 45445
5 66434 Met Top Hinge UNI Slope OPT for 45445 9
66523 Harness, F-M Moduled V7 for 45445 3 66526
Self Closing, Steek-TSL BK W/Wire for
45445
6
To Next Page
