Parts Breakdown
Model G372 41220
Model G372 BLACK 45250
General Assembly
Evaporator Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
66545 Clip Pilaster Shelf for 41220 & 45250 1 66580 Louvered for 41220 & 45250 3 66581 Back Grill G3T72 for 41220 & 45250 5
66579 Louvered Left Cut for 41220 & 45250 2 45247 Black Shelf for 41220 & 45250 4
Item No. Description Position Item No. Description Position Item No. Description Position
66582 Evaporator Housing for 41220 & 45250 1 66585 Evaporator Coil for 41220 & 45250 4 66588 Cap Tube for 41220 & 45250 7
66583
Evaporator Housing Left for 41220 &
45250
2 66586
ELCO Evaporator Motor Without Blade
for 41220 & 45250
5 66396 Knob, ABS Control for 41220 & 45250 8
66584
Evaporator Housing Right for 41220
& 45250
3 66587
Evaporator Motor Blade for 41220 &
45250
6 66530
Controller ELE BEV 115V N/SEN for
41220 & 45250
9
Item No. Description Position Item No. Description Position Item No. Description Position
66536
LED Driver, VDM#3017356 for 41220
& 45250
1 66554 Condensate Pan 6LT for 41220 & 45250 4 66589
Power Cord 20 AMP 10 FT for 41220
& 45250
7
66538
Compressor SEC NF 11FX 115V 60HZ
for 41220 & 45250
2 66555 Filter Drier VAL22TDV for 41220 & 45250 5
64182 Condenser Coil Elite for 41220 & 45250 3 66551
Evaporator Condenser Fan Motor G319
V10 for 41220 & 45250
6
Item No. Description Position Item No. Description Position Item No. Description Position
66597
Top Right Hinge Bracket G342 for 41220
& 45250
1 66590 Left Door without LED for 41220 & 45250 6 66594 Self Closing Right for 41220 & 45250 11
66598
Bottom Right Hinge Bracket G342 for
41220 & 45250
2 66591
Right Door without LED for 41220 &
45250
7 66595
LED Series G326 Left Door for 41220
& 45250
12
66599
Bottom Left Hinge Bracket G342 for
41220 & 45250
3 66592 Door Gasket for 41220 & 45250 8 66596
LED Series G319x42 Right Door for
41220 & 45250
13
66600
Top Left Hinge Bracket G342 for 41220
& 45250
4 66459
Door Handle, PLA Standard V7.2 for
41220 & 45250
9
66557 Door Support for 41220 & 45250 5 66593 Self Closing Left for 41220 & 45250 10
