Omcan Imbera VFS24 User Manual

75
Parts Breakdown
Model VR1.5 45800 General Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
66530
Controller, ELE BEV 115V N/SEN for
45800
1 66393
Leveling Screw, 1/2”-13x2” W/PLA UL
for 45800
4 66400
Thermometer, Wall MTG, 3017492 for
45800
7
AD623 Grill, Met Unit UL BR for 45800 2 AD624 Shelf, LAR for 45800 5
66399 Clip, F/Pilaster 16G Polished for 45800 3 AD625 Shelf, SMA for 45800 6
Item No. Description Position Item No. Description Position Item No. Description Position
AD626 Cap Tube, 0.024”x150” N/S for 45800 1 66417 Filter, Drier 0.9 HP DCL for 45800 5 66469 Temp Sensor, ETC1H 1.0M for 45800 9
AD627 Harness, Main UL LED for 45800 2 AD630 Harness, Compressor UL LED for 45800 6 66425
Power Cord, 115V 15A 14AWG for
45800
10
AD628
Compressor SEC TF3.5F 115V 60Hz
for 45800
3 66402 Rocker Switch, BK for 45800 7
AD629 Condenser, STA 11T 3/16 FE for 45800 4 66449
LED Driver, VB-12030D018 30W
115V50/60Hz for 45800
8
Item No. Description Position Item No. Description Position Item No. Description Position
66480 Hinge Top OPT BL Cover for 45800 1 66455 Module, 6 LEDS 1.2W 12V for 45800 4 66459 Door Handle, PLA STD V7.2 for 45800 7
66434
MET Top Hinge UNI Slope OPT for
45800
2 AD632 Door G J RIG LED SCC BDH for 45800 5
AD631 Hinge, MET Top RIG SCC for 45800 3 AD633
Door Gasket, Universal 354x675mm
for 45800
6

Omcan Imbera VFS24 Specifications

General

Brand	Omcan
Model	Imbera VFS24
Category	Refrigerator
Language	English
