Omcan Imbera VFS24 User Manual

79
Parts Breakdown
Model VR04 45801 General Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
AD634 Temperature Control for 45801 1 AD636 Grommet for 45801 8 AD641 Leveling Leg for 45801 15
AD635 Control Box for 45801 2 AD637 Back Grill for 45801 9 AD642 Front Grill for 45801 16
AD579 Control Knob for 45801 3 AD638 Grommet for 45801 10 AD643 Front Grill Support for 45801 17
66469 Temp Sensor, ETC1H 1.0M for 45801 4 AD639 Shelf for 45801 11 AD644 Clip Molding for 45801 18
AD572 Power Cord for 45801 5 66645 Clip F/Pilaster for 45801 12 AD645 Main Harness for 45801 19
AD568 Switch for 45801 6 AD640 Pilaster for 45801 13 AD583 Motor Ground Harness for 45801
66449
LED Driver, VB-12030D018 30W 115V
50/60Hz for 45801
7 66507
Thermometer, Wall MTG, 3017492 for
45801
14 AD646 Compressor Harness for 45801
Item No. Description Position Item No. Description Position Item No. Description Position
AD647 Compressor Base for 45801 1 AD597 Filter Drier for 45801 7 66512
Motor E WEL 1/70HP 115V 50/60Hz
1800RPM for 45801
13
AD648 Compressor for 45801 2 AD652 Discharge Pipe for 45801 8 66476
Nylon T Motor Injected Support for
45801
14
AD649 Condenser for 45801 3 66419 Charge Pipe 1/4” 0.180M for 45801 9 66408
Fan Blade MYF PLA 6” Dia. 31 Deg.
for 45801
15
AD650 Condensate Pan for 45801 4 AD653 Vacuum Pipe for 45801 10 AD656 ACC Compressor Kit for 45801 16
AD596 Condenser Pan Support for 45801 5 AD654 Suction Line for 45801 11
AD651 Capillary Tube 0.031”x150” for 45801 6 AD655 Motor Stand for 45801 12
Item No. Description Position Item No. Description Position Item No. Description Position
AD657 LED Module for 45801 1 66526
Self Closing, Steel-TSL BK with Wire
for 45801
6 AD663 Hinge Cover for 45801 11
AD658 F-M Module Harness for 45801 2 AD616 Plastic Door Handle for 45801 7 AD664 Moulding Glass Fixer Cover for 45801 12
AD659 F-Driver Module Harness for 45801 3 AD617 Removable Rivet for 45801 8 AD665 Moulding Glass Fixer Cover for 45801 13
AD660 Glass Door for 45801 4 66456
MET Bottom Hinge RIG SCC TR34.5
for 45801
9
AD661 Gasket for 45801 5 AD662 Top Hinge for 45801 10
