Omcan Imbera VFS24 User Manual

84
Parts Breakdown
Model VFS24 41221 General Assembly
Evaporator Assembly
Condenser Assembly
Door Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
62480 Back Grill G3D42 for 41221 1 66645 Clip, F/Pilaster for 41221 4 66507
Thermometer, Wall MTG, 3017492 for
41221
7
66643 Shelf for 41221 2 66646 Pilaster for 41221 5 66647 Metallic Front Grill for 41221 8
66644 Floor Shelf for 41221 3 66393
Leveling Screw, 1/2”-13x2” W/PLA UL
for 41221
6 66648 Controller for 41221 9
Item No. Description Position Item No. Description Position Item No. Description Position
66649 Evaporator for 41221 1 66655 White Evap Housing for 41221 7A 66661 Drain Gasket for 41221 10
66650 Cap Tube for 41221 2 66656 Black Evap Housing for 41221 7B 66662 Heater for 41221 11
66651 Return Pipe for 41221 3 66657 White Grill, Wire Fan Blade for 41221 8A 66663 Grommet for 41221 12
66652 Bimetal Disc for 41221 4 66658 Black Grill, Wire Fan Blade for 41221 8B 66664
Evaporator Fan Motor, 13W 1800RPM
for 41221
13
66653 Evap Pan for 41221 5 66659 White Couple for 41221 9A 66424
Fan Blade, Wel Pla 8” Diam. 28 Deg.
for 41221
14
66654 Heater for 41221 6 66660 Black Couple for 41221 9B 66493
ABS O Motor Evaporator Support for
41221
15
Item No. Description Position Item No. Description Position Item No. Description Position
64182 Condenser Coil Elite for 41221 1 66667 Cap Extension Pipe for 41221 6 66670 Vacuum Pipe for 41221 11
66665 Compressor NT2168GKV for 41221 2 66668
Condenser Fan Motor, 16W 1850RPM
for 41221
7 66671 Discharge Pipe for 41221 12
66666 Compressor Accessories for 41221 3 66477
Fan Blade ELC PLA 8” Diam. 28 Deg.
for 41221
8 66672 Suction Pipe for 41221 13
66518 ABS Condenser Pan EV46x72 for 41221 4 66493
ABS O Motor Evaporator Support for
41221
9 66673 Temperature Sensor for 41221 14
66555 Filter Drier VAL22TDV for 41221 5 66669 Charge Pipe for 41221 10
Item No. Description Position Item No. Description Position Item No. Description Position
66674 Glass Door for 41221 1 66676 Bottom Hinge for 41221 3 66677 Outer Gasket for 41221 5
66675 Top Hinge for 41221 2 66577 Module, 6 LEDS 1.2W 12V for 41221 4 66678 Inner Gasket for 41221 6
