Omega Engineering OS136 SERIES User Manual

Figure 3-4. Stainless Steel Housing
Figure 3-5. Water/Air Cool Jacket, OS136-WC
Figure 3-6. Water/Air Cool Jacket Assembly
Operation
3
5
LIGHT HEX KNURL
4.76 (3/16) WIDE
DIMENSIONS mm (in)
3/4-16 UNF
88.9
(3.5)
1.83m
(6ft)
33.27
(1.31)
19.05
(0.75)
1/8 NPT COMPRESSION
FITTING, 2 PLCS.
34.80
(1.37)
85.09
(3.35)
7.62
(0.30)
3/4-16 UNF-2B
3/4-16 UNF
INLET OUTLET
Dimensions mm (in.)
MOUNTING
BRACKET
OUTLETINTLET
OS137
UP TO 200°C (392°F) AMBIENT TEMPERATURE WITH WATER COOLING
MOUNTING
NUT
Dimensions mm (in.)
