Section 5 – Recorder Setup
Page 65 09/11/2008 REV 0.99
Event Message: Enter the event message that will be printed in the alarm event log (and the recorded file if
enabled) in this Box. The message may be up to 20 characters in length.
Master Enable: When checked this allows external events to be recognized by the system. When unchecked
ALL external events are ignored. This allows setup without the possibility of an external event triggering the
system unexpectedly. It can also disable external events temporarily without having to reprogram inputs.
Print on Demand: This button brings up the channel selector which allows selection of which
channels will have a status printout when the input is active. The printout is serial ASCII and
outputs through the (optional) serial port only. It can be used to communicated with a remote controller or
print to a serial printer.
