Sensor U.U.T. DMM
Step Select Output Adjust Reading*
1 K 32.0°F P1 0.000 mV ±1µV
2 K 2500.0°F P41 54.856 mV ±1µV
3 Repeat Steps 1 & 2 As Required
4 J 32.0°F P1 0.000 mV ±1µV
5 T 32.0°F P1 0.000 mV ±1µV
6 E 32.0°F P1 0.000 mV ±1µV
7 N 32.0°F P1 0.000 mV ±1µV
8 B 1000.0°F P1 1.439 mV ±1µV
9 R 32.0°F P1 0.000 mV ±1µV
10 S 32.0°F P1 0.000 mV ±1µV
11 **G** 600.0°F P1 2.238 mV ±1µV
12 C 32.0°F P1 0.000 mV ±1µV
13 D 32.0°F P1 0.000 mV ±1µV
Table 2: Calibrator-Mode Zero & Gain Adjustments
** exclusive of noise.
** on EC models, G replaced by L. Calibrate L per J.
Sensor U.U.T. U.U.T.
Step Select Input Adjust Reading*
1 K 0.000 mV P1 32.0 ±0.1°F
2 K 54.856 mV P11 2500.0 ±0.1°F
3 Repeat Steps 1 & 2 As Required
4 J 0.000 mV P1 32.0 ±0.1°F
5 T 0.000 mV P1 32.0 ±0.1°F
6 E 0.000 mV P1 32.0 ±0.1°F
7 N 0.000 mV P1 32.0 ±0.1°F
8 B 1.439 mV P1 1000.0 ±0.5°F
9 R 0.000 mV P1 32.0 ±0.5°F
10 S 0.000 mV P1 32.0 ±0.5°F
11 **G** 2.238 mV P1 600.0 ±0.2 °F
12 C 0.000 mV P1 32.0 ±0.2°F
13 D 0.000 mV P1 32.0 ±0.2°F
Table 1: Meter-Mode Zero & Gain Adjustments
** exclusive of noise.
** on EC models, G replaced by L. Calibrate L per J.
26

Omega 24 Specifications

General

Display Type	LCD
Accuracy	±0.5°C
Resolution	0.1°C
Probe Type	Stainless steel
Measurement Range	-50 to 300°C (-58 to 572°F)
