Contents
OMEGA SA WORLD SERVICE ORGANIZATION GT-19-C-024-E - C - 3220
Page
Calibre 3220 1
General information for Calibre 3220 3
Basic movement assembly 3
Lubricating the Swiss-lever escapement 3
Measuring instruments 3
Tightening and untightening torques according to screw thread 3
Mandatory tools / Lubricants 3
Exploded views for calibre 3220 4-16
Assembly - chronograph module 4-16
Specifi c information for calibre 3220 17-22
Disassembling the chronograph module 17
Inspection during re-assembly 17-19
Inspection + adjusting the hammer 19-20
Chronograph System Operation 20
Setting the time / Chronograph Operation 21
Runners for hand setting and hand setting force / Instantaneous rate 22
Spare parts list for calibre 3220 23-32
List and plate for chronograph module supplies 23-27
List and plate for movement supplies 28-31
List of jewels and bushes 32
Modifi cations of Technical Guide version for Calibre 3220 33
