/4
Assembly - Chronograph module for Calibre 3220
OMEGA SA WORLD SERVICE ORGANIZATION GT-19-C-024-E - C - 3220
31.044
31.040
1251
Press
Movement
holder
Second train
driving wheel
Second train
wheel small plate
Screw for second
train driving
wheel small plate
Additional minute
train bridge
assembled
Screw for
additional
minute train
Ref.
1
2
3
4 5
Ref. 30.029 Ref. 15.050 Ref. 3448 Ref. 10.062 Ref. 3445
1.0 Parts for assembling
Check that the wheel is free
(ref. 30.029) use an air blower. Do not
lubricate the second gear train driving
wheel pivoting.
!
Moebius SYNT HP-1300 Sans Colorant
2.0 Pre-lubrication
3.0 Order of assembly
2
3
1
5
4
!
Check the height of the friction spring (see page 18).
