Assembly - Chronograph module for Calibre 3220
OMEGA SA WORLD SERVICE ORGANIZATION GT-19-C-024-E - C - 3220
Moebius SYNT HP-500
Moebius SYNT HP-1300 Sans Colorant
Movement
holder
Hour counter
intermediate
wheel
Hour counter
driving wheel
Minute counter
driving wheel
Chronograph
wheel
Support jewel for
center wheel
Ref.
1
2
3
4 5
Ref. 35.033 Ref. 35.031 Ref. 35.013 Ref. 35.010 Ref. 1594
1.0 Parts for assembling
2.0 Pre-lubrication
3.0 Order of assembly
1
2
3
4
Press
Check that the friction spring is
positioned correctly (see page 18).
!
!
