Assembly - Chronograph module for Calibre 3220
OMEGA SA WORLD SERVICE ORGANIZATION GT-19-C-024-E - C - 3220
Movement
holder
Chronograph bridge Screw for chronograph bridge Screw for chronograph bridge
Ref.
1
2
3
Ref. 10.047 Ref. 3513 Ref. 2837
2.0 Pre-lubrication
3.0 Order of assembly
Check that the wheel is free use an air
blower.
!
!
2
3
1
Check the end shake of moving
chronograph parts!
!
1.0 Parts for assembling
Moebius SYNT HP-500
