Omega DP20 Quick Installation Guide

10. Regulaons
This instrument conforms to the actual CE regulaons. For a copy of the ‘CE declaraon
of conformity’ see secon 3. Applicable regulaons are :
Security regulaons EN-61010-1 (‘Fixed’ equipment, ‘Permanently connected’.
‘Double’ isolaon. ‘CAT-II’ category)
Electromagnec compability regulaons EN-61326-1
According to direcve 2012/19/EU, electronic equipment must be re-
cycled in a selecve and controlled way at the end of its useful life.
This instrument does not provide a general mains switch and will start operaon as
son as power is connected. The instrument does not provide protecon fuse, and the
fuse must be added during installaon.
Risk of electrical shock. Instrument terminals can be connected to
dangerous voltage.
Instrument protected with double isolaon. No earth connecon
required.
Instrument conforms to CE rules and regulaons.
Range, scaling and decimal point 0/600 Vac = 0/600
Alarm 1 as maximum
Setpoint 1000
Hysteresis 0 counts
Alarm 2 as maximum
Setpoint 1000
Hysteresis 0 counts
External control o
Fast access all o
Tools
Opon 1 o (retains last conguraon value)
Step 1
Average 0
Manual oset 0
Second scaling 0/600
‘Eco’ mode o
Temperature resoluon 1º
Degrees ºC
Alpha 385
cJc on
AC ‘deadband’ 20
Luminosity 3
Password o
Opon
Analog output 0/100.0=4/20 mA
Serial Modbus RTU 9600 bps, address 1, format 8n1
Jumpers ‘S’ range for 600 Vac
Jumper ‘T’ external contact ‘EK’ funcon
11. Factory conguraon
9. Conguraon menu
Press ‘SQ’ (<) for 1 second to access
the ‘Conguraon menu’.
Input
AC signals
600 V
200 Vac
20 Vac
2 Vac
200 mVac
60 mVac
5 Aac
20 mAac
DC signals
±600 Vdc
±200 Vdc
±20 Vdc
±2 Vdc
±200 mVdc
±60 mVdc
±5 Adc
±20 mAdc
Process
4/20 mA
0/10 Vdc
Thermocouples
thermocouple K
thermocouple J
thermocouple E
thermocouple N
thermocouple L
thermocouple R
thermocouple S
thermocouple B
thermocouple T
thermocouple C
NTC probes
Resistances
0 to 5 K
0 to 50 K
Alarm 1
Setpoint
Hysteresis
Type
Alarm 2
Setpoint
Hysteresis
Type
Temp.
resoluon.
1º resoluon
0.1º resoluon
Scaling 2
Decimal
Display Low
Display High
‘Eco’ mode
5 to 255 sec.
Filter
0 a 100
Steps
Oset
Decimal 1
Decimal 2
Decimal 0
Scaling 2
Decimal 3
Opon 1
analog
relay
NoneTools
Modbus RTU
enters the
analog output
calibration
menu
Scaling
Decimal
Display Low
Display High
Key UP
Maximum
Minimum
Setpoint 1
Setpoint 2
Minimum
Hold
Maximum
External
control
Disabled
Alpha
Alpha 385
Alpha 390
Front keypad menu operaon
Key SQ (<) - 1. Press to access the ‘Conguraon menu’.
2. Press to enter into the actual menu entry.
3. Press to accept a value.
Key UP (5) - 1. Press to access the ‘Fast access’ menu.
2. Press to move through available menu opons.
3. Press to increase the value of a numerical parameter.
Key LE (3) - 1. Without funcon.
2. Press to return to a previous level of the menu, discarding changes (to
validate changes, use SQ (<)).
3. Move through the digits of a numerical parameter.
To save the conguraon changes, press key LE (3) unl exing the menu (shown by
ashing decimal points). Instrument shows the signal range selected and starts opera-
on with the new conguraon.
PTC probes
KTY 121
KTY 210 and 220
Minimum
Brightness
Maximum
Standard
Password
Version
Factory reset
‘AC deadband’
‘Deadband’ on AC
ranges. Value 0 to 100.
Opon 1
conguraon
Analog
Display Low
Display High
Modbus RTU
Address
Speed
1 to 247
9600 bps
4800 bps
Format
Cold juncon
Thermocouple cold juncon
compensaon ‘on’ or ‘o’
Degrees
Celsius
Fahrenheit
RTD probes
Pt100 (2 wires)
Pt500
Pt1000
Ni100
Ni200
Ni1000
Pt100 (3 wires)
Potenometer
If you need addional informaon, see secon 3 to download
the full User’s Manual.
12. User’s manual
!
www.omega.com/ DP20.html
600U
600U
tArE
Tare funcon
Frequency
FrEq
Note: The AC powered units cannot be shipped to Canada.
